METABEE Mini USB Type-B 5 ピン レセプタクル、PCB マウント、スルーホール、垂直

METABEE Mini USB Type-B 5-Pin Receptacle, PCB Mount, Through Hole, Vertical

The Mini USB Type-B 5-Pin Receptacle is a high-reliability, single-port connector designed for vertical through-hole PCB mounting. Engineered for durability, it features brass contacts with a gold-plated finish, ensuring excellent conductivity and corrosion resistance for stable 1A current and 30V AC voltage operation. Its HiTemp thermoplastic insulation with a UL94 V-0 flammability rating provides superior heat resistance and safety. The shielded metal shell effectively minimizes electromagnetic interference (EMI), safeguarding signal integrity. With robust specifications including a maximum contact resistance of 50 mΩ, minimum insulation resistance of 100 MΩ, and the ability to withstand 100 VAC for one minute, this connector delivers consistent performance across an operating temperature range of 20°C to 60°C. It is the ideal solution for embedded systems, industrial controls, and consumer electronics requiring a dependable mini USB interface.
