Metabee 6P4C RJ11 模块化插孔,剥皮镀锡线,面板安装,26AWG,UL 1061,黑色

SKU: MTJP-623-P4-X-A1-1
MPN: MTJP-623-P4-X-A1-1

主要特点

  • UL 1061 26AWG 电线提供经过认证的安全性和可靠性。
  • 标准 6P4C 配置非常适合双线语音连接。
  • 时尚的黑色外壳提供坚固耐用的通用工业配合。
  • 精密镀锡引线无需准备电线并加快组装速度。
  • 坚固的面板安装框架可确保安全、长期的连接。
有现货
数量
1
单价
¥ 31.45
总价
¥ 31.45
¥ 31.45
数量
单价
总价
1+
¥31.45
¥ 31.45
10+
¥29.88
¥ 298.80
50+
¥28.31
¥ 1415.50
200+
¥26.74
¥ 5348.00
属性
值
制造商
亚当
颜色
黑色的
连接器类型
RJ11
接触完成
镀金镀镍
额定电流
1A
安装类型
面板安装
接触材料
铜合金
介电耐压
1000VAC 1分钟
额定电压
150VAC
模型
623P4
绝缘电阻
≥500MΩ
接触电阻
<20mΩ
线规
26 AWG,UL 1061
品牌
梅塔比
工作温度
-40°C 至 125°C
外壳材料
聚对苯二甲酸丁二醇酯
引线端接
剥皮和镀锡线
描述
  • UL 1061 26AWG wire provides certified safety and reliability.
  • Standard 6P4C configuration is ideal for dual-line voice connections.
  • Sleek black housing offers a rugged, universal industrial fit.
  • Precision tinned leads eliminate wire prep and speed assembly.
  • Robust panel mount frame ensures a secure, long-term connection.

Metabee 6P4C RJ11 Modular Jack, Stripped and Tinned Wire, Panel Mount, 26AWG, UL 1061, Black

Safety meets standardized performance in the Metabee 6P4C RJ11 Modular Jack. This SKU is specifically engineered for dual-line voice applications and standard data interfaces where regulatory compliance is a non-negotiable priority. Featuring UL 1061 26AWG wiring, this jack maintains electrical integrity even in environments prone to temperature fluctuations, offering a robust insulation profile that saves space without compromising protection.



The classic Black housing is crafted from high-impact thermoplastic, providing a stable mechanical lock that prevents port displacement during frequent plugging cycles. With factory-stripped and tinned leads, this "ready-to-integrate" component significantly reduces production cycle times for OEM manufacturers. This jack is more than just a connector; it is a safety-certified bridge for your communication hardware, combining the universal 6P4C interface with modern, rigorous industrial standards. Perfect for office telephony, security panels, and standardized electronic devices requiring a professional, black-finish external port.
